THE BEAM PATTERN
If you’re looking for a driving light that offers near-field spread, keep moving, this is not that. The optical properties of the hooded reflector design is best described as high-beam on steroids. The ST-X excels in the high-speed, high-way application when mid to long-range visibility is critical.
- Significantly minimises adverse reflection from road signs
- Controlled vertical spread minimises reflections off of high-mounted road signs.
KEY FEATURES
- 16x 15W LEDs
- LED Parking / Position Light Function (Amber or White built-in)
- Breather allows pressure equalisation when rapid heat up and cool down cycles occur
- Anodized Polyester Powder Coat
- Weatherproof Deutsch® DTP Connector
- Includes adjustable Side brackets & Sliding bottom brackets
- Includes our Easy-Fit Plug & Play High Beam Wiring Harness with HB3 & H4 adapter (Compatible with both negative and positive switched vehicles)
- Protected against reverse polarity
- Shockproof, IP68 waterproof, UV Shielded
- Protected Against RFI / EMC Interference
- Voltage & current surge protection
- Pulse Width Modulation Thermal Management
| VOLTAGE | 9-36V |
| AMPERES | 17.2A @ 12V (full power), 3.28A @ 12V (limit power) |
| POWER | 206.4W (full power), 39.36 (limit power) |
| LUMENS | 8400LM (full power), 2327LM (limit power) |
| COLOUR TEMPERATURE | 5000k |
| AMP RATING | 0.5a |
| PHOTOMETRIC DATA | 1 lux @ 859m (full power), 1 lux @ 450m (limit power) |
| LENS MATERIAL | OPTICAL GRADE, HARD-COATED LEXAN |
| HOUSING MATERIAL | 6063 EXTRUSION |
| INGRESS PROTECTION | IP68 |
| CANDELAS | 739582 @ full power, 203337 @ limit power |
| CONNECTOR | 60cm cable with DTP 4in |
| OPERATING TEMP | -40°C ~ +60°C |
| CERTIFICATES | R112, ref. 50 and R10 |
| LIFESPAN | 50, 000hrs (LM80) |
| PRODUCT WEIGHT | 3.7kg |
| SHIPPING WEIGHT | 4.2kg |
