KEY FEATURES
- Registered Design: 201915829.
- CREE® XLamp XP-L HI undomed LEDs using CREE’s breakthrough SC5 Technology™
- RFI and EMI suppression circuit. Guaranteed to not interfere with Radio or GPS Equipment
- IP68 – Submersible to 3m
- High Current Deutsch DTP-2 25A connectors
- 32mm diameter parabolic reflectors
- Spread and Spot beam pattern
- 4mm thick 304 stainless steel side brackets included.
- Cast Alloy adjustable sliding bracket included.
- Nitto Denko™ Breather with PTFE microporous membrane
- Very heavy-duty Smart Plug & Play ADR compliant Wiring Harness. (Switch, Dual Fuse, Dual Relay and HB3 and H4 Piggyback Adaptors) included
Tech Specs
- Led – 40 x CREE XPL Hi-Intensity LED
- VOLTAGE – 9V – 32V
- CURRENT DRAW (AMPERES) – 25.3a @13.6v
- RAW LUMENS – 43,800Lm
- EFFECTIVE LUMENS – 22,400Lm
- PEAK INTENSITY (CANDELA) – 656,100cd
- COLOUR TEMP (CCT) – 5700K
- LENS MATERIAL – Optical Grade, Hard-Coated Lexan
- HOUSING MATERIAL – A360.0 Cast face plate, extruded Aluminum heat sink
- INGRESS PROTECTION – IP68
- FLOOD BEAM – 50°
- SPOT BEAM – 9°
- LIFESPAN – 50,000hrs
- OPERATING TEMP – -40°C ~ +150°C
- WEIGHT – 4.960kg
